An auto-contrast colour aesthetic — aes

A colour aesthetic for annotation that automatically contrasts with fill. Can be spliced into ggplot2::aes with rlang::!!!.

Usage

aes_contrast(mode_family = "light", dark = NULL, light = NULL)

Arguments

mode_family: The mode family to optimise light and dark colours for. Options are "light", "grey" or "dark".
dark: A dark colour. If NULL, uses mode_family optimised colour.
light: A light colour. If NULL, uses mode_family optimised colour.

Value

An aesthetic

Examples

library(ggplot2)
library(dplyr)
#>
#> Attaching package: ‘dplyr’
#> The following objects are masked from ‘package:stats’:
#>
#>     filter, lag
#> The following objects are masked from ‘package:base’:
#>
#>     intersect, setdiff, setequal, union
library(stringr)
library(palmerpenguins)

set_blanket()

penguins |>
  count(species, sex) |>
  gg_col(
    x = sex,
    y = n,
    col = species,
    label = n,
    position = position_dodge2(preserve = "single"),
    width = 0.75,
    x_labels = \(x) str_to_sentence(x),
  ) +
  geom_text(
    mapping = aes_contrast(),
    # mapping = aes(!!!aes_contrast()),
    position = position_dodge2(width = 0.75, preserve = "single"),
    vjust = 1.33,
    show.legend = FALSE,
  )


penguins |>
  count(species, sex) |>
  gg_col(
    x = sex,
    y = n,
    col = species,
    label = n,
    position = position_dodge2(preserve = "single"),
    width = 0.75,
    x_labels = \(x) str_to_sentence(x),
    mode = dark_mode_r(),
  ) +
  geom_text(
    mapping = aes_contrast("dark"),
    #' mapping = aes(!!!aes_contrast("dark")),
    position = position_dodge2(width = 0.75, preserve = "single"),
    vjust = 1.33,
    show.legend = FALSE,
  )
